*Fiber max. distance 2km(mm),15km(sm)
Note: Other fiber connector and transmission distance are available.
PoE port Port 1-4, auto power management
Pin assignment: TX(1,2), RX(3,6), V+(4,5), V-(7,8)
Maximum PoE power Per port 56V 35W
PoE disconnect mode DC disconnect
PoE auto detection IEEE802.3af/at
PoE protection Over-temperature, over-current, over/under voltage
LEDs *Link/Activity (Green ON/ Green Blinking every 43ms @100Mbps/
Green Blinking every 120ms @10Mbps)
*PoE(Yellow) On-PD detect, Blinking-error detect)
*POWER Green-normal, Red-alarm
Power input AC 90-264VAC, 47-63Hz.
DC 24V (12V~36V).
Power consumption 5W without PD loading
Operating temperature -20℃~ 85℃
Operation humidity 90% relative humidity, non-condensing
Storage temperature -55℃~+105℃
Dimension 44mm(H)x210mm(W)x199mm(D)
19” rack mount available with brackets
