Characteristics:
Input and Output characteristics:
(Input voltage)
1.Rated input.
2.Rated input+10%
3.Rated input-10%
Functioning:Connect with the actual set and confirm the function.
Continuous Current-Carrying:
Temperature:+40℃.
Power voltage: Rated voltage.
Load: Rated load.
Duration: 96 hours.
Confirm the function after leaving the test part in nominal temperature and humidity for 1 hour
Over-voltage Continuous Current-Carrying:
Applicable only for parts with rated inputs more than 200V.
Temperature:+50℃.
Input voltage: 280V.
Duration: 48 hours.
Load: Select larger load with the primary current under no load or rated load condition. Periodically observe the test part during test.
Confirm the function after leaving the test part in nominal temperature and humidity for 1 hour.
Bend:
Number of action: 500 times.
Speed of action: 30 times per minute.
Load: 500g.
Use a bending machine to give specified load to the test part, and swing it left and right at 60angle against perpendicular.
Confirm outward appearance after test.
